High-Quality 15-Inch Patient Monitoring System with Multi-Language Support

1 / 5

High-Quality 15-Inch Patient Monitoring System with Multi-Language Support

Customization:	Available
Classification:	Physiological Functions of Diagnosis and Monitoring Equipment
Type:	Patient Monitor

Send Inquiry

Product Description

Basic Specifications

Model NO.

SYP-P-7000

Certification

CE, FDA, ISO13485

Group

Middle-aged and Old

Data Storage

96-Hour Tabular

NIBP Protection

Dural Over Pressure Protection

Anti-Interference

High-Frequency & Defibrillation Protected

Screen

12.1" Touch Screen

Origin

China

Product Overview

SYP Multi-Language 12.1 Inches Cardiac Monitor System

This professional medical equipment is designed to monitor vital parameters including ECG, RESP, SpO2, NIBP, and Dual-channel TEMP. It integrates a parameter measuring module, high-resolution display, and recorder into a single compact, portable device. The built-in replaceable battery ensures continuous monitoring during patient movement.

📋 Key Features

12.1'' color TFT LCD with high-resolution display for waveforms and alarms.
Applicable for adult, pediatric, and neonatal patients.
Multi-language support: English, French, German, Italian, Dutch, Portuguese, Turkish, Spanish, Polish.
Storage of 480-hour trend data and 2400 NIBP data sets.
Digital SpO2 technology with strong anti-interference capability.
Networkable: Supports wireless and wired connection to central stations.
Built-in rechargeable battery for uninterrupted operation.
Drug concentration calculation and HRV analysis (optional).

Technical Performance

Parameter	Specifications & Range
ECG	3-lead and 5-lead optional; HR Range: 15 ~ 300 bpm; Accuracy: ±1% or ±1bpm.
Respiration	Method: R-F(RA-LL) Impedance; Range: 0~120rpm; Accuracy: ±2 rpm.
NIBP	Method: Oscillometry; Modes: Manual, Auto, Continuous; Range: 10~270mmHg.
SpO2	Measuring Range: 0 ~ 100%; Accuracy: 70% ~ 100% ±2%.
TEMP	Dual-channel; Range: 0 ~ 50°C; Accuracy: ±0.1°C.
EtCO2 (Optional)	Sidestream or Mainstream; Range: 0~150mmHg; AwRR Range: 2~150 rpm.
IBP (Optional)	Dual-channel; Labels: ART, PA, CVP, RAP, LAP, ICP, P1, P2; Range: -50~350 mmHg.

📏 Physical Characteristics

Dimension: 310 × 140 × 263 (mm)

Net Weight: 3.8 Kg

📦 Standard Accessories

Adult SpO2 probe (5-pin)
Adult NIBP cuff & Extending tube
ECG lead & Electrodes
Temperature probe
Power cord & User Manual

❓ Frequently Asked Questions

Q1: Which vital signs can this monitor track? A: The standard configuration monitors ECG, RESP, SpO2, NIBP, and dual-channel TEMP. Optional modules for IBP and EtCO2 are also available.

Q2: Is the device suitable for all patient types? A: Yes, the system is designed with specific modes and protections for adult, pediatric, and neonatal patients.

Q3: How much data can the monitor store? A: It can store up to 480 hours of trend data, 72 hours of ECG waveforms, and 2400 sets of NIBP measurements for comprehensive review.

Q4: Does it support international use? A: Yes, the interface supports multiple languages including English, French, German, Spanish, Portuguese, and more.

Q5: Can it be used during surgery? A: Yes, it features anti-high frequency surgical unit interference and is defibrillation-proof to ensure safety in operating rooms.

Q6: Is the monitor portable? A: Absolutely. It weighs only 3.8kg and includes a built-in rechargeable battery and a carrying handle for easy transport.
