🩺 Product Description
AED biphasic defibrillator with monitor function can meet all of your clinical requests from Basic Life Support (BLS) to Advanced Cardiac Life Support (ACLS).
Technical Specifications
- Display: 7 inch high resolution LCD display; Sweep Speed: 25mm/sec.
- Monitoring Info: HR, Lead/Pads, On/Off Alarm, SpO2, AED Functions and Prompts, Alarm Selection and Limits, Delivered Energy.
- Defibrillator Feature: Biphasic waveform; Charge Time less than 7 seconds with a new fully charged battery.
- ECG Monitoring: 5-lead or 3-lead ECG cable/paddles; Heart Rate 20-300BPM; Smart Alarms for shockable rhythm.
- SpO2 Module: Measurement Range 30~100%; Alarm Accuracy ± 10%.
- Recorder: 50mm thermal paper; High-resolution thermal print head; Manual or automatic modes.
⚡ Operation Modes
AED Mode
Auto analyze and charge X3 with programmable auto energy level selection, screen prompts, and voice prompts. Detects Ventricular fibrillation and tachycardia.
Manual Mode
Energy Selection: 2, 5, 7, 10, 20, 30, 50, 70, 100, 150, 200, 300, 360 joules. Synchronized Mode available.
Frequently Asked Questions
What type of waveform does the DM7000 use?
The DM7000 utilizes a Biphasic waveform, which is the current standard for effective defibrillation.
How long does the battery last during continuous use?
A new, fully charged Ni-MH 12V battery provides minimum 3 hours of continuous ECG monitoring or up to 60 discharges at maximum energy.
What is the maximum energy level in Manual Mode?
In Manual Mode, the device offers energy selection up to 360 Joules, with various increments starting from 2 Joules.
Does the device provide voice prompts?
Yes, the device features both voice and visual prompts to guide the user during AED operations and charging processes.
What are the display specifications?
The unit is equipped with a 7-inch high-resolution LCD display that shows HR, Lead/Pads info, SpO2, and AED functions.
What certifications does this medical device hold?
The DM7000 is certified with CE and ISO13485, ensuring it meets international medical quality and safety standards.
